644 carb mod; what to do
Topic Started: Oct 25 2012, 04:24 PM (743 Views)
iwata
Commoner
[ * ]
hi lads can anyone tell me which pipes have to be blanked off when doing the carb mod on a 644 , am i rite in thinking its only two to blank off ive had a scan on here but cant find anything defo , if anyone has pictures that would be ace thanks for your help
Offline Profile Quote Post Goto Top

Monty
Member Avatar
Charlie Big Banana's
[ *  *  *  *  *  *  *  *  *  * ]
Cant help with a pic, but there are 2 points to blank on the carbs, both on the right carb, you will have 2 rubber pipes, one goes to the top of carb on the white plastic cover, and the other is centre of the inlet manifold.

Remove pipes and blank either buying the proper blanks from suzuki, or cutting the rubber tube and fitting a bolt in the end

the solenoid under the carbs can be removed and the pipework hidden under the tank, tuck the plug and cable up out of the way
If it aint sharp I can play with it
My Utube Channel, lots of bike vids here. Subscribe if you likehttp://www.youtube.com/user/choppermark?feature=watch

Posted Image
Offline Profile Quote Post Goto Top

bighit
outta here
[ *  *  *  *  *  *  *  *  *  * ]
can you use diesel injector spill pipe blanks monty?

http://www.ebay.co.uk/itm/10-X-DIESEL-LEAK...=item41652b7b50

can get them cheaper than that in most auto parts stores
Offline Profile Quote Post Goto Top

RudiRulez
Member Avatar
The Boss
[ *  *  *  *  *  *  * ]
http://www.4shared.com/office/AFtE9jwo/Thr...e_Lift_Con.html

Download that for a How to PDF.

There should be a pic of the 2 points you need to block just below this sentence, let me know if its showing for you.

Posted Image
Posted Image
Offline Profile Quote Post Goto Top

bighit
outta here
[ *  *  *  *  *  *  *  *  *  * ]
pic is there rudi
Offline Profile Quote Post Goto Top

whitebuck
Member Avatar
Dazed and confused
[ *  *  *  *  *  *  *  *  * ]
Thanks Monty for posting the instructions and Rudi for the pics ...... I've been wondering about this for ages :flowers:

Now where's those carbs I got off Tom :rolleyes: :rolleyes:
Posted Image
Ride It Like It's Your Ex G/F
CCMMaD Hoodies, Sweats and T shirts http://www.omegaprintandsigns.co.uk/
Offline Profile Quote Post Goto Top

iwata
Commoner
[ * ]
cheers lads for your help and rudi for the great pics , my 644 is on a 56 plate and must of been done at the factory as the top spout had been done so i only had to do the bottom one , the bike had only done 1800 miles and one owner and was totally standard , thanks again trev ps had a bastard with the inlet rubbers lol
