size of the holes in the airbox lid?
Topic Started: Apr 6 2012, 09:30 AM (474 Views)
yoshimura
Member Avatar
Knight
[ *  * ]
Hi,
i bought a ccm r30 and at the bike was no airbox lid/top-plate, because the seller of the bike lost it in his garage..... . It was not ready to drive with this jetting (main jets 115, twinair filter). I made a plate by my self and changed the main jets up to 135. But with the new kn filter it feels the gas/air mix is to poor.
i think the holes with 35mm are to big, can tell my someone whats the original size of the holes?


cheers
Joe
Posted Image
Offline Profile Quote Post Goto Top

Tricky
Member Avatar
Earl
[ *  *  *  *  * ]
If you have a race can fitted then 25mm holes should do it.

i lost mine and had to make a dummy one, i put four holes in it and it runs well right through the rev range. It's a little twitchy on tick over but thats about it. Probably running a little rich but better to run rich than too lean.

Edit: Just noticed your perpex jobby. Looks better than mine - i just used a piece of cardboard wrapped in insulation tape. :lol:
Offline Profile Quote Post Goto Top

yoshimura
Member Avatar
Knight
[ *  * ]
Hi,
thanks for the reply. so my holes are much to big and i try to close two of them with isulationtape :D

regards joe
Offline Profile Quote Post Goto Top

Monty
Member Avatar
Charlie Big Banana's
[ *  *  *  *  *  *  *  *  *  * ]
Original lid has 6 holes, these were opened up to 25mm and worked well will 135 mains and std pilots, plus race can.

area of 25mm hole is 4.9cm X 6 holes = 29.4cm

area of 35mm hole is 9.62cm X4 holes = 38.48cm

So guess to get correct air flow only block of one hole not 2.
If it aint sharp I can play with it
My Utube Channel, lots of bike vids here. Subscribe if you likehttp://www.youtube.com/user/choppermark?feature=watch

Posted Image
Offline Profile Quote Post Goto Top

yoshimura
Member Avatar
Knight
[ *  * ]
Oh thanks, i forget there was 6 holes at standard.

Offline Profile Quote Post Goto Top

Marc
Member Avatar
Marquess
[ *  *  *  *  *  * ]
Or just get rid of the airbox completely if you like...
CCM 644,Kent cam,Braking wavy disc and 4pot caliper,Brembo radial m/c etc etc

Posted Image
